HAXO-8

The LogTag HAXO-8 Temperature and Humidity Data Logger measures and stores up to 8000 sets of high resolution humidity and temperature readings over a measurement range of 0 to 100%RH & -40°C to +85°C (-40°F to +185°F).

Using the LogTag Interface Cradle and the freely available companion LogTag Analyzer Software, the LogTag® HAXO-8 temperature humidity recorder is easily set-up for recording including delayed start, sampling interval, number of readings and configuration of conditions to activate the 'ALERT' indicator.

LogTag^® Analyzer also provides facilities for charting, zooming, listing data statistics and allows exporting the data to other applications such as MS Excel once the data has been downloaded.

Features

Record high resolution Temperature & Humidity readings simultaneously
Rapid download - Typically less than 5 seconds data download
Re-calibration - Maintain reading accuracy throughout product life
Alerts for humidity & temperature
Replaceable air filter
IMPORTANT: Each location (not each logger) requires a LogTag Cradle in order to program and retrieve data from the logger.

Specifications

Model	HAXO-8
Humidity Measurement Range	0 ~ 100%RH but with limitations as detailed in Humidity Measurement Operating and Storage conditions below.
Temperature Measurement Range	-40°C to +85°C (-40°F to +185°F)
Humidity Resolution	Better than 0.1%RH
Temperature Resolution	better than 0.1°C or 0.1°F
Accuracy
Capacity	8000 pairs of humidity & temperature readings (32Kbytes memory)
Sampling Frequency	Adjustable, 30 sec to several hours
Logging Start Options	Push button start or specific date & time.
Recording Indication	Flashing 'OK' indicator / flashing 'ALERT' indicator.
Download Time	Typically with full memory (8000 readings) in less than 10 secs depending on computer or readout device used.
Environmental	IP61 (when hung or mounted vertically)
Power Source	3V LiMg battery
Battery Life	2 ~ 3 years of normal use (based on 15 minute logging, download data monthly.
Size	86mm(H)x54.5mm(W)x8.6mm(T)
Weight	35g
Case Material	Polycarbonate
Other Features	Logging start by push button or specific date/time start Real time clock Quick start Optional clearing of alert indication by push button (places inspection make at same time). Download inspection mark recorded in LogTag memory every time LogTag is downloaded. 'Prestart' fail-safe logging (records temperature data even if not started) Low Battery indication in software. Comprehensive Alert indicator configuration. Calibration to achieve higher accuracy possible. Adjustable sampling interval Optional Wall Mount

Applications

Musical Instrument environmental monitoring
Cave environmental monitoring
Mushroom farming
Product Storage and Transportation
Calibration rooms
Greenhouse environmental monitoring
Warehouses
Basements, crawlspaces and attics
Cigar humidors
Office environment monitoring
Commercial environmental monitoring
Apartment environmental compliance verification
